| Provides 20 Nl/min of compressed from an 8 bar Oil Free compressor | Quiet: noise level reduced to a minimum thanks to special soundproof and anti-vibration devices |
| Possible parallel connection up to 4 stackable tower configuration generators | CPU with Touch Screen Display that can be linked to the generators with CAN-BUS, allowing monitoring of the operating status and menu reading with the maintenance status, the alarm report and functional parameters |
| FLOW RATE | 20 Nl/min ± 2 Nl/min up to 2000 m from the sea |
| TECHNOLOGIES EMPLOYED | Oil free piston compressor |
| OUTPUT PRESSURE | 0÷8 bar ± 3% (± 240 mbar) |
| AIR OUTPUT CHARACTERISTICS | Particulate = 0.01 mm Moisture = -15° C dew point ATP |
| ELECTRICAL SUPPLY | 220 Vac ±10% 50 Hz 550 VA |
| INDEX OF PROTECTION | IP20 |
| NOISE | < 55 dBA |
| OPERATING TEMPERATURE | 5°C - 40°C/40°F - 100°F |
| ENVIRONMENTAL HUMIDITY | max 90% without condensation |
| DIMENSIONS | Height: 40 cm + 7 cm (base) /15.8” + 2.8” Width: 38 cm/14.9” Depth: 53 cm/20.8” |
| WEIGHT | 25 kg/55 lbs |
| PNEUMATIC CONNECTIONS | Purified air output: G 1/8” female |
